Features of KFD-3 Load cell Transmitter
◆Adjustable stable voltage.
◆Voltage counter-connection protection.
◆Zero adjustable resistors can be outer connected.
◆Terminal tabs connection.
Specifications of KFD-3 Load cell Transmitter
(Current output)
◆Supply voltage DC 12V,15V,24V
◆Output：4-20mA(or 0-10mA, 0-20mA)
◆Load resistance：≥500 （24V Working)
◆Accuracy：better than 0.1%F.S
◆Operating temperature：-20℃~+85℃
Specifications of KFD-3 Load cell Transmitter
(Voltage output)
◆Supply voltage：DC 12V,15V,24V
◆Output：0-5VDC(or 1-5VDC,0-10VDC,0-±5VDC)
◆Load resistance：≥500Ω(24V working)
◆Accuracy：better than 0.02%F.S(current)
◆Operating temperature:-20℃-+85℃
