Model | KAL-11-2.4V |
Frequency Range (MHZ) | 2400-2483 |
Input Impedance (Ω) | 50 |
VSWR | <1.5 |
Gain (dB) | 12 |
HPBW (3dB) | 7°E-plane |
Maximum Power (W) | 100 |
Polarization | Vertical Polarization |
Connctor type | N-K |
Lighting Protection | Direct Ground |
Wind Velocity (KM/H) | 200 |
Length (mm) | 1000 |
Declination Angle | 5° |
Hold Pole Diameter (mm) | φ40-φ50 |
